M9037A at a Glance
M9037A at a Glance
The following figure shows the front panel for the M9037A. Detailed information
about the module follows in this manual.
DisplayPort Connectors
GPIB
USB 2.0 Ports*
SMB Trigger
LED Indicators
Connector
USB 3.0 Ports
PCIe Connector
Handle for
LAN (GbE)
Port #1
LAN (GbE)
Port #2
LAN Reset
PCIe Link Speed
Connector
(supports multiple monitors
Indicator
removing
button
* The USB 2.0 and 3.0 ports do not support the USB Battery Charging specification. Do not connect non-standard or defective
USB devices.
