Keysight M937xA PXIe Service Guide 2-23
Tests, Adjustments, and Troubleshooting
System Verification
Performing System Verification
The following verification procedure is automated by the network analyzer
firmware. The process for the verification is:
- connect cables to the analyzer test ports
-perform a calibration or recall a recent calibration
- run the system verification program for the verification devices
Each time through the verification process, you are prompted to make
necessary connections and perform or recall a calibration as part of performing
the verification. If you select to perform a calibration, you are guided through
the calibration procedure. This part of the process can be eliminated if you
choose to load an existing recent calibration. If necessary, refer to the network
analyzer’s Help system for information on storing and recalling calibrations.
For each verification device, the analyzer reads a file from the verification disk
and sequentially measures the magnitude and phase for all four S-parameters.
Equipment Used in the System Verification Procedure
For system verification to perform correctly, it is NECESSARY that the
verification devices be measured with their female connectors connected
to the network analyzer’s Port 1 and male connectors to Port 2.
Although the performance for all S-parameters are measured, the S
11
and
S
22
phase uncertainties for the attenuators and airlines are less important
for verifying system performance. Therefore, the limit lines will not appear
on the printout.
Table 2-1 Equipment Used in the System Verification Procedure
Equipment Type 3.5 mm Type-N
Calibration kit 85052B, C, D
N4691B ECal
85054B/D
N4690B ECal
Verification kit 85053B 85055A
Cables Single cable: 11500E
Cable pair: 11500E and
8121-2111
Single cable: 11500E with 1250-1744 adapter
Cable pair: 11500E with 1250-1744 adapter, and 8121-2111 with
1250-1750 adapter
Adapters None required With single cable: an 85130C adapter and a 7 mm to Type-N
adapter from the 85054B calibration kit.
With cable pair: Two 7 mm to Type-N adapters from the 85054B
calibration kit.
