N9030B PXA Signal Analyzer Service Guide 389
Replaceable Parts
Replaceable Parts
W45 Cable, coax, Step Cal, Digital IF J17 to Wideband Analog IF J805
(Option B1X)
8121-1401
W46 Cable, coax, Step Cal, Wideband Analog IF J806 to
Reference Board J726 (Option B1X)
8121-0152
W47 Cable, coax, Step Cal, A3 Digital IF J17 to Reference board J726
(Required if no Option B1X, B2X, B5X)
8121-1401
W50 Reserved
W51 Cable, semi-rigid, Input attenuator B to Switch 3 port 1
(Options 503, 508, 513, 526 with Option LNP or MPB)
N9020-20143
Cable, semi-rigid, Input attenuator B to Switch 3 port 1
(Options 544, 550 with Option LNP or MPB)
N9020-20171
W52 Cable, semi-rigid, Switch 3 port 4 to A11 Low Band Switch J1
(Options 503, 508, 513, 526 with Option LNP or MPB)
N9020-20146
Cable, semi-rigid, Switch 3 port 4 to A11 Low Band Switch J1
(Options 544, 550 with Option LNP or MPB)
N9020-20125
W53 Cable, semi-rigid, Switch 3 port 2 to Switch 2 Port C
(Options 503, 508, 513, 526 with Option LNP or MPB)
N9020-20144
W54 Cable, semi-rigid, Switch 3 port 3 to A11 Low Band Switch J3
(Options 503, 508, 513, 526 with Option LNP or MPB)
N9020-20145
Cable, semi-rigid, Switch 3 port 3 to A11 Low Band Switch J3
(Options 544, 550 with Option LNP or MPB)
N9020-20127
W55 Cable, ribbon, Low Band Switch Bypass Control.
Switch 3 to A15 Front End Controller J802
(Options 503, 508, 513, 526 with Option LNP or MPB)
N9020-60087
Cable, ribbon, Low Band Switch Bypass Control.
Switch 3 to A15 Front End Controller J802
(Options 544, 550 with Option LNP or MPB)
N9020-60177
W56 Cable, semi-rigid, Low band Switch assy J3 to YTF input
(Options 503, 508, 513, 526 without Option MPB or LNP)
N9020-20123
Cable, semi-rigid, Low band Switch assy J3 to YTF input
(Options 544, 550 without Option MPB or LNP)
N9010-20005
W57 Cable, semi-rigid, YTF output to Front End assy J9
(Options 503, 508, 513, 526 without Option MPB or LNP)
N9020-20124
Cable, semi-rigid, YTF output to Front End assy J9
(Options 544, 550 without Option MPB or LNP)
N9010-20006
W59 Cable, semi-rigid, Switch 3 Port 2 to Switch 4 Port 1
(Options 544, 550 with Option LNP or MPB)
N9020-20151
Table 15-1 All Replaceable Parts
Reference
Designator
Description Part Number
