392 Chapter 15 Replaceable Parts Replaceable Parts
Table 15-2 Attaching Hard ware
Attach To Qty Part Number Type Tool Torque
Analog IF Digital IF 3 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Attenuators Attenuator Bracket 2 per 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Attenuator Bracket Chassis 2 per 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Backlight Inverter Board Inverter Bracket 2 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Backlight Inverter Top Shield Backlight Inverter Bottom
Shield
8 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Chassis Bottom Chassis Front & Side Brackets 15 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Chassis Front Bracket Chassis 10 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Chassis Gusset Chassis 3 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Chassis Side
(Right Outside)
Chassis 8 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
CPU Assembly Chassis 6 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
CPU Top Shield CPU Assembly 3 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
19 0515-1227 M3 X 0.5
(6 mm long)
Torx T-10 9 inch-lbs
Display Display Bracket 4 0515-0367 M2.5 X 0.45
(8 mm long)
Torx T-8 5 inch-lbs
