Chapter 15 395
Replaceable Parts
Replaceable Parts
Rear Feet Rear Panel 4 0515-1619 M4 X 0.7
(25 mm long)
Torx T-20 21 inch-lbs
4 3050-0893 Flat Washer n/a n/a
Rear Frame Chassis 5 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Rear Frame Hole Cover Rear Frame Inner Hole Cover 16 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Reference Assembly Chassis 2 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
RF Front End Assembly Chassis 6 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
RF Input Connector Chassis 2 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Strap Handles Chassis Side 2 per 0515-0710 M4 X 0.8
(18 mm long)
Torx T-20 21 inch-lbs
Top Brace Chassis 12 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Chassis & PCB Assemblies 12 0515-1946 M3 X 0.5
(6 mm long)
Torx T-10 9 inch-lbs
Transfer Switch Transfer Switch Bracket 3 0515-1934 M2.5 X 0.45
(6 mm long)
Torx T-8 6 inch-lbs
Transfer Switch Bracket Chassis 2 0515-2032 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Low Band Switch Bracket 1 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Table 15-2 Attaching Hard ware
Attach To Qty Part Number Type Tool Torque
