Parameter Typical Return
DIO | DINPut | FAULt| INHibit| ONCouple |
OFFCouple TINPut | TOUTput
DIO, DINP, FAUL, INH, ONC, OFFC, TINP,
or TOUT
Sets pin 1 to FAULt mode: DIG:PIN1:FUNC FAUL
[SOURce:]DIGital:PIN<1-7>:POLarity POSitive|NEGative
[SOURce:]DIGital:PIN<1-7>:POLarity?
Sets the pin polarity. POSitive means a logical true signal is a voltage high at the pin. For trigger inputs
and outputs, POSitive means a rising edge. NEGative means a logical true signal is a voltage low at
the pin. For trigger inputs and outputs, NEGative means a falling edge. The pin polarities are saved in
non-volatile memory.
Parameter Typical Return
POSitive|NEGative POS or NEG
Sets pin 1 to POSitive polarity: DIG:PIN1:POL POS
[SOURce:]DIGital:TOUTput:BUS[:ENABle] 0|OFF|1|ON
[SOURce:]DIGital:TOUTput:BUS[:ENABle]?
Enables or disables BUS triggers on digital port pins. This allows a BUS trigger to be sent to any digital
port pin that has been configured as a trigger output. A trigger out pulse is generated when the state is
on and a bus trigger is received. A BUS trigger is generated using the *TRG command.
Parameter Typical Return
0|OFF|1|ON, *RST OFF 0or1
Enable BUS triggered signals on the digital pins: CURR:TOUT:BUS ON
l The query returns 0 (OFF) if the trigger signal will NOT be generated with a BUS trigger command,
and 1(ON) if a trigger signal will be generated with a BUS trigger command.
5 SCPI Programming Reference
188 Keysight RP7900 Series Operating and Service Guide
