Keysight Technologies RP7942A User Manual

Test Equipment and Setups
Test Equipment
Measurement Setups
Test Equipment
The test equipment recommended for the performance verification and adjustment procedures is
listed below. If the exact instrument is not available, substitute calibration standards of equivalent
accuracy.
Instrument Requirements Recommended Model Use
1
Digital Multimeter Resolution: 10 nV @ 1V;
Readout: 8 1/2 digits
Accuracy: 20 ppm
Keysight 3458A V, C
Current Shunt
2
100 A (0.01Ω) 0.01%, TC=4ppm/ΩC
300 A (0.001Ω ) 0.01%, TC=4ppm/ΩC
1000A, 0.1mΩ 0.02%, TC=25ppm/ΩC
Guildline 9230A/100
Guildline 9230A/300
Guildline 9230A/1000 or equivalent
V, C
Electronic load
and source
2
20 V, 800 A, 10 kW
80 V, 250 A, 10 kW
160 V, 125 A, 10 kW
500 V, 40 A, 10 kW
950 V, 20 A, 10 kW
Keysight RP7933A or RP7943A
3
Keysight RP7935A or RP7945A
3
Keysight RP7936A or RP7946A
3
Keysight RP7952A or RP7962A
3
Keysight RP7953A or RP7963A
3
V
DC power supply
4
80 V, 40 A Keysight RP7935A/RP7945A
3
or equivalent
C
GPIB controller Full GPIB capabilities Keysight 82350B or equivalent V, C
Oscilloscope Sensitivity: 1 mV
Bandwidth: 20 MHz
Probe: 10:1 with RF tip
Probe: 100:1 with RF tip
Keysight DSO6054A or equivalent
Keysight 10073D
Keysight 10076C
V
RMS Voltmeter True RMS
Bandwidth: 20 MHz
Sensitivity: 100 μV
Rhode and Schwartz Model URE3
or equivalent
V
Differential Amplifier Bandwidth: 20 MHz LeCroy 1855A, DA1850A, or equivalent V
Differential Probe 10:1/100:1 selectable LeCroy DXC100A, or equivalent V
Terminations 50Ω BNC termination V
1
V=Verification; C=Calibration
2
Dependent on output voltage rating of the model being tested
3
Dependent on the AC mains available at the test facility (either 208 VAC 3ø or 480 VAC 3ø)
4
Required for calibration on models RP795xA/RP796xA only
6 Verification and Calibration
