Parameter Typical Return
BUS|CURRent1 | EXTernal | PIN<1-7> | TRANsient1
| VOLTage1, *RST BUS
BUS, CURR1, EXT, PIN<n>, TRAN1, or VOLT1
Selectdigital port pin 1 as the measurement trigger source: TRIG:ACQ:SOUR PIN1
TRIGger:ARB:SOURce <source>
TRIGger:ARB:SOURce?
TRIGger:ELOG:SOURce <source>
TRIGger:ARB:SOURce?
TRIGger:TRANsient:SOURce <source>
TRIGger:TRANsient:SOURce?
TRIG:ARB:SOURce - Selects the trigger source for arbitrary waveforms:
TRIG:ELOG:SOURce - Selects the trigger source for external data logging:
TRIG:TRANsient:SOURce - Selects the trigger source for the transient system:
BUS Selects a remote interface trigger command.
EXTernal Selects ALL digital port pins that have been configured as trigger sources.
IMMediate Triggers the transient as soon as it is INITiated.
PIN<1-7> Selects a digital port pin configured as a trigger input.
Parameter Typical Return
BUS | EXTernal | IMMediate| PIN<1-7> *RST BUS BUS, EXT, IMM, PIN<n>
Selectdigital port pin 1 as the Arb trigger source: TRIG:ARB:SOUR PIN1
Selectdigital port pin 1 as the transient trigger source: TRIG:TRAN:SOUR PIN1
5 SCPI Programming Reference
234 Keysight RP7900 Series Operating and Service Guide
