26 Chapter 5
Amplitude Accuracy at 50 MHz
Procedure
h. Record the signal amplitude, as measured by the analyzer in the
Measured Amplitude column of Table 5-1
i. Calculate the signal amplitude accuracy error using the following
equation, and record the results under the Amplitude Accuracy
Error column:
Amplitude Accuracy Error = Meas_amp − Power_meter
Table 5-1 Amplitude Accuracy Results
Nominal
Source
Amplitude
(dBm)
Attenuation
(dB)
Span
(MHz)
Measured
Amplitude
Meas_amp
(dBm)
Power Meter
Amplitude
Power_meter
(dBm)
Amplitude
Accuracy
Error
(dB)
Test Limit
(dB)
−4102 ±1.13 dB
−9101 ±1.13 dB
−14100.5 ±1.13 dB
−4200.1 ±1.13 dB
−14200.1 ±1.13 dB
−4300.1 ±1.13 dB
−14 30 0.1 ±1.13 dB
