Measurements 15
Keysight InfiniiVision 3000T X-Series Oscilloscopes User's Guide 247
“Average" on page 254 Yes, Full
Screen
“Base" on page 252
“Bit Rate" on page 261 Yes
“Burst Width" on page 260
“Counter" on page 259 Yes Not valid for math waveforms.
“Delay" on page 261 Measures between two sources.
Press Settings to specify the second
source.
“Duty Cycle" on page 260 Yes
“Fall Time" on page 261
“Frequency" on page 258 Yes
“Maximum" on page 251 Yes
“Minimum" on page 251 Yes
“Rising Edge Count" on
page 266
“Falling Edges Count" on
page 266
“Positive Pulse Count" on
page 265
“Negative Pulse Count" on
page 265
“Overshoot" on page 252
“Peak-Peak" on page 251 Yes
“Period" on page 258 Yes
“Phase" on page 262 Measures between two sources.
Press Settings to specify the second
source.
Measurement Valid
for
Math
FFT
*
Valid for
Digital
Channels
Notes
