Keysight E36300 Series Service Guide

Performance Verification
Performance verification ensures that the instrument performs within the specifications stated in the data sheet
(http://literature.cdn.keysight.com/litweb/pdf/5992-2124EN.pdf)
Recommended test equipment
The test equipments recommended for the performance verification and adjustment procedures are listed below. If
the exact instrument is not available, use the accuracy requirements shown to select substitute calibration
standards.
Type Specification Recommended model
Digital multimeter Readout: 6 1/2 digits Basic DC Accuracy: 0.0035% Keysight 34401A or equivalent
Current monitor 15 A (0.1 Ω), TC = 4 ppm/°C Guildline 9230A-15R
Electronic load 150 V, 5 A minimum, with transient capability and a slew rate of
833 kA/s or better.
Keysight N3300A mainframe, with
N330xA modules
Fixed load Wirewound resistor 300 W, 1.6 Ω or equivalent
– E36311A/E36312A Output 1: 1.2 Ω
– E36313A Output 1: 0.6 Ω
Wirewound resistor 225 W, 25 Ω or equivalent
– E36311A/E36312A Output 2 and 3: 25 Ω
– E36313A Output 2 and 3: 12.5 Ω
Ohmite MPN: E300K1R6E
Ohmite MPN: E225K25RE
LAN / USB controller N/A PC with Keysight Connection Expert
loaded
Oscilloscope Sensitivity: 1 mV; Bandwidth Limit: 20 MHz Probe: 1:1 with RF
tip
Keysight Infiniium/6054A or equivalent
RMS voltmeter True RMS; Bandwidth: 20 MHz Sensitivity: 100 μV Rhode and Schwartz model URE3 or
equivalent
Differential amplifier Bandwidth: 20 MHz LeCroy 1855A or equivalent
Terminations 1 – 50 Ω BNC termination
2 – 50 Ω, ≥ 1/8 W resistor
N/A
Variable voltage transformer or
AC source
Adjustable to highest rated input voltage range. Power: 500 VA Keysight 6813B or equivalent
Calibration resistors for low
range current
– E36312A/E36313A Output 1: 300 Ω power resistor, ≥ 1 W
– E36312A/E36313A Output 2 and 3: 2.5 kΩ power resistor,
≥ 1 W
N/A
