E36312A Report Number ____________ Date ______________
Description Outputs Lower limit Result Upper limit
Constant Current Tests
Current Programming
Minimum Current Output (I
0
)
Maximum Current Ouput (I
max
)
Output 1
Output 2
Output 3
Output 1
Output 2
Output 3
-0.001 A
-0.002 A
-0.002 A
4.995 A
0.9976 A
0.9976 A
______________
______________
______________
______________
______________
______________
0.005 A
0.004 A
0.004 A
5.005 A
1.0024 A
1.0024 A
Current Readback
Minimum Current measured over interface
Maximum Current measured over interface
Output 1
Output 2
Output 3
Output 1
Output 2
Output 3
I
0
- 0.003 A
I
0
- 0.003 A
I
0
- 0.003 A
I
max
- 0.005 A
I
max
- 0.0034 A
I
max
- 0.0034 A
______________
______________
______________
______________
______________
______________
I
0
+ 0.003 A
I
0
+ 0.003 A
I
0
+ 0.003 A
I
max
+ 0.005 A
I
max
+ 0.0034 A
I
max
+ 0.0034 A
CC Load Regulation (I
load
- I
short
) Output 1
Output 2
Output 3
-750 μA
-350 μA
-350 μA
______________
______________
______________
750 μA
350 μA
350 μA
CC Line Regulation (I
lowline
- I
highline
) Output 1
Output 2
Output 3
-750 μA
-350 μA
-350 μA
______________
______________
______________
750 μA
350 μA
350 μA
Low Range Current Measurement
Maximum Low Range Current measured over inter-
face
Output 1
Output 2
Output 3
I
low max
- 130 µA
I
low max
- 105 µA
I
low max
- 105 µA
______________
______________
______________
I
low max
+ 130 µA
I
low max
+ 105 µA
I
low max
+ 105 µA
Test Description Instrument settings
Output 1 Output 2 Output 3
Voltage Programming & Readback, Zero Voltage (V
0
) 0 V, 5 A 0 V, 1 A 0 V, 1 A
Voltage Programming & Readback, Maximum Voltage (V
max
) 6 V, 5 A 25 V, 1 A 25 V, 1 A
CV Load Regulation, Line Regulation, Ripple and Noise 6 V, 5 A 25 V, 1 A 25 V, 1 A
Transient Response 6 V, 2.5 Ato 5 A 25 V, 0.5 Ato 1 A 25 V, 0.5 Ato 1 A
Current Programming & Readback, Minimum Current (I
0
) 0.002 A, 6 V 0.001 A, 25 V 0.001 A, 25 V
Current Programming & Readback, Maximum Current (I
max
) 5 A, 6 V 1 A, 25 V 1 A, 25 V
CC Load Regulation, Line Regulation, Ripple and Noise 5 A, 6 V 1 A, 25 V 1 A, 25 V
Low Range Current Readback, Maximum Low Range Current
(I
low max
)
0.02 A, 6 V 0.01 A, 25 V 0.01 A, 25 V
