Keysight Infiniium S-Series Oscilloscopes User’s Guide 3
Infiniium S-Series Oscilloscopes—At a Glance
Table 1 S-Series oscilloscopes
Model Analog
bandwidth
Maximum sampling
rate (2-channel)
Standard memory depth
(2/4-channel mode)
DSOS054A/MSOS054A 500 MHz 20 GSa/s 100 Mpts/50 Mpts
DSOS104A/MSOS104A 1 GHz 20 GSa/s 100 Mpts/50 Mpts
DSOS204A/MSOS204A 2 GHz 20 GSa/s 100 Mpts/50 Mpts
DSOS254A/MSOS254A 2.5 GHz 20 GSa/s 100 Mpts/50 Mpts
DSOS404A/MSOS404A 4 GHz 20 GSa/s 100 Mpts/50 Mpts
DSOS604A/MSOS604A 6 GHz 20 GSa/s 100 Mpts/50 Mpts
DSOS804A/MSOS804A 8 GHz 20 GSa/s 100 Mpts/50 Mpts
