24 Keysight InfiniiVision 1000 X-Series Oscilloscopes User's Guide
1 Getting Started
Front Panel Overlays for Different Languages
Front panel overlays, which have translations for the English front panel keys and
label text, are available in many languages. The appropriate overlay is included
when the localization option is chosen at time of purchase.
To install a front panel overlay:
1 Gently pull on the front panel knobs to remove them.
2 Insert the overlay's side tabs into the slots on the front panel.
3 Reinstall the front panel knobs.
20. USB Host port This port is for connecting USB mass storage devices or printers to the oscilloscope.
Connect a USB compliant mass storage device (flash drive, disk drive, etc.) to save or recall
oscilloscope setup files and reference waveforms or to save data and screen images. See
“Save/Recall (Setups, Screens, Data)" on page 79.
To print, connect a USB compliant printer. For more information about printing see “Print
(Screens)" on page 82.
You can also use the USB port to update the oscilloscope's system software when updates are
available.
You do not need to "eject" the USB mass storage device before removing it. Simply ensure that any
file operation you've initiated is done, and remove the USB drive from the oscilloscope's host port.
CAUTION: Do not connect a host computer to the oscilloscope's USB host port. A host
computer sees the oscilloscope as a device, so connect the host computer to the oscilloscope's
device port (on the rear panel). See “Learn the Rear Panel Connectors" on page 25.
