Keysight N4693D User Manual

Electronic Calibration Modules Reference Guide 5-15
Specifications and Characteristics
Characteristic Performance
Table 5-27 Characteristic Performance for N4692D (2.92 mm)
Parameter Frequency Range
DC to
45 MHz
a
10 MHz
to
45 MHz
b,c
45 MHz
to
200 MHz
200 MHz
to 2 GHz
2 GHz
to 20 GHz
20 GHz
to 30 GHz
30 GHz
to 40 GHz
Transmission Tracking (±dB)
d
0.13 0.28 0.11 0.10 0.14 0.17 0.21
Load Match (dB)
d
35 27 34 35 33 28 27
a. For Option 0DC.
b. For Option 010.
c. For Option 003.
d. Values based on using the network analyzer N5224B Option 200.
Table 5-28 Characteristic Performance for N4693D (2.4 mm)
Parameter Frequency Range
DC to
45 MHz
a
10 MHz
to
45 MHz
b,c
45 MHz
to
200 MHz
200 MHz
to 2 GHz
2 GHz
to 10 GHz
10 GHz
to 20 GHz
20 GHz
to 40 GHz
40 GHz
to 50 GHz
Transmission Tracking
(±dB)
d
0.08 0.18 0.08 0.04 0.05 0.07 0.11 0.15
Load Match (dB)
d
36 24 41 45 40 35 33 30
a. For Option 0DC.
b. For Option 010.
c. For Option 003.
d. Values based on using the network analyzer N5225B Option 200.
