5-16 Electronic Calibration Modules Reference Guide
Specifications and Characteristics
Characteristic Performance
5-
Table 5-29 Characteristic Performance for N4694D (1.85 mm)
Parameter Frequency Range
DC to
45 MHz
a
10 MHz
to
45 MHz
b
45 MHz
to
200 MHz
200 MHz
to 2 GHz
2 GHz
to
20 GHz
20 GHz
to
30 GHz
30 GHz
to
40 GHz
40 GHz
to
50 GHz
50 GHz
to
60 GHz
60 GHz
to
67 GHz
Transmission
Tracking (±dB)
c
0.12 0.28 0.08 0.08 0.08 0.09 0.11 0.14 0.15 0.22
Load Match (dB)
c
35 22 36 36 37 33 32 31 28 24
a. For Option 0DC.
b. For Option 010.
c. Values based on using the network analyzer N5227B Option 200.
Table 5-30 Characteristic Performance for N4696D (7 mm)
Parameter Frequency Range
DC to
2 MHz
a
2 MHz to
10 MHz
a
300 kHz
to 2 MHz
b
2 MHz
to 10
MHz
b
10 MHz
to 500
MHz
500 MHz
to 2 GHz
2 GHz
to 10 GHz
10 GHz
to 18 GHz
Transmission Tracking (±dB)
0.17
c
0.05
c
0.37
c
0.08
c
0.10
d
0.04
d
0.05
d
0.08
d
Load Match (dB)
36
c
41
c
26
c
37
c
33
d
39
d
41
d
34
d
a. For Option 0DC.
b. For Option 003.
c. Values based on using the network analyzer N5231B Option 200.
d. Values based on using the network analyzer N5222B Option 200.
