14 | Keysight | N9038A MXE EMI Receiver Self-Guided Demonstration - Demo Guide
Demo 3: Delete or add signals
The MXE allows you to edit a signal list by marking and deleting signals or adding a
signal at the current marker frequency. The MXE offers flexible features to adjust the
frequencies of signals in the signal list as shown in Table 2. EMC engineers spend a lot
of time optimizing the signal list during the data reduction and radiation maximization
process.
In this demonstration, we will use {Mark Signals} and {Delete Marked} functions to delete
signals from signal list. We will also use the {Mkr List} function to add additional
signals to the signal list.
Step 2—Demo 3 Instructions for MXE Keystrokes
Select a signal from signal list and mark it
mark by pushing {Mark Signal}
You can mark more signals in the same way
Delete the marked signal [Return], {Delete Signals} {Delete Marked} to delete all marked signals
Or {Delete Signal} to delete the current signal
Add a peak into signal list using
[Peak Search]
Table 2. Summary of keystrokes for adjusting the frequencies of the suspect signals
Category Descriptions Key strokes
Move to frequency Move meters to marker frequency
Move marker to meters frequency
Move meters to the frequency of the closest signal
Add to list Add marker frequency to list
Couple frequencies Add meters frequency to list
Replace current signal frequency with meters
frequency
Couple frequencies Couple meters frequency to current signal; the blue
line for meters frequency follows the current signal
when navigating signals
[Mode Setup], {Meters Control}, {Couple Meters to Signal List}
Couple meters frequency to current marker; the blue
line for meters frequency follows current marker
movement
[Mode Setup], {Meters Control}, {Couple Meters to Marker}
