MAINTENANCE
7-34
5. Install a new headlight bulb in the
three (3) slots on the headlight
assembly and snap the headlight bulb
retaining wire into position.
6. Connect the headlight bulb electrical
connector.
7. Install the headlight bulb cover by
turning it clockwise.
FRONT FOG LIGHT
REPLACEMENT
(IF EQUIPPED)
1. Turn the bulb socket counter-
clockwise and remove the bulb socket.
2. Insert a new bulb in socket.
3. Install the bulb socket.
REAR COMBINATION
LIGHT BULB
REPLACEMENT
1. Using a cross-tip screwdriver,
remove the cover.
2. Turn the bulb socket counter-
clockwise and remove it from the
housing.
3. Push the bulb in, then rotate it one-
quarter turn counterclockwise and
remove the bulb from the socket.
EMSA7027
EMSA7028
