Kia Optima PHEV 2018 - Engine Room Compartment Fuse Panel

875
Maintenance
Fuse Name Fuse rating Circuit Protected
MULTI
FUSE
MDPS 1 80A MDPS Unit (Column)
COOLING FAN 60A RLY. 2 (Cooling Fan Relay)
B+5 50A
PCB Block (Engine Control Relay, Fuse -FUEL PUMP/ECU2/TCU1/HORN/WIPER1/BATTERY
C/FAN)
B+3 50A Smart Junction Block (IPS 2 (IPS 5), IPS 3 (IPS 6), IPS 7, IPS 8)
REAR HEATED 50A RLY. 11 (Rear Heated Relay)
ACTIVE
HYDRAULIC
BOOSTER 2
40A Integrated Brake Actuation Unit
BLOWER 40A RLY. 4 (Blower Relay)
POWER
OUTLET1
40A RLY. 7 (Power Outlet Relay)
IG2 30A PCB Block (IG2 Relay)
Engine room compartment fuse panel
