Fuse Name Fuse rating Circuit Protected
MULTI
FUSE
B+1 60A
Smart Junction Block (Fuse - TRUNK, SUNROOF2, S/HEATER REAR, SUNROOF1, P/WDW RH,
P/SEAT PASS, P/WDW LH, P/SEAT DRV)
EEWP 60A Engine Electric Water Pump
B+2 60A Smart Junction Block (IPS 1, IPS 4, Fuse - FOG LAMP REAR, S/HEATER FRONT, AMP)
ACTIVE
HYDRAULIC
BOOSTER 1
40A Integrated Brake Actuation Unit
IG1 40A PCB Block (IG1/ACC Relay)
PTC
HEATER 1
50A PTC HEATER
To Next Page
