877
Maintenance
Fuse Name Fuse rating Circuit Protected
FUSE
EPB1 30A Electric Parking Brake Module
H/Lamp Washer 30A RLY. 9 (H/Lamp Washer Relay)
B+4 40A
Smart Junction Block (Leak Current Autocut Device Fuse - INTERIOR LAMP, MULTI MEDIA, MEM-
ORY2, MEMORY1, Fuse - MODULE1, DR LOCK, SMART KEY, BRAKE SWITCH)
EPB 2 30A Electric Parking Brake Module
OPCU 1 20A Electric Oil Pump Unit
DEICER 20A RLY. 10 (Deicer Relay)
AMS 10A Battery Sensor
HEATED MIRROR 10A A/C Control Module, Driver/Passenger Power Outside Mirror
WIPER 2 10A BCM, PCM
H/LAMP HI 20A RLY. 6 (Head Lamp High Relay)
HEV ECU 1 10A HPCU
OPCU2 10A Electric Oil Pump Unit
ELECTRICAL
WATER PUMP
10A Electric Water Pump (HEV)
