Maintenance
Instrument panel (Driver’s side fuse panel)
Fuse Name Symbol Fuse rating Protected Component
MODULE3 7.5A Sport Mode Switch, Key Solenoid (W/O Smart Key)
PDM1 25A Smart Key Control Module (With Smart Key)
POWER
OUTLET
15A Front Power Outlet
MODULE5 7.5A
Smart Key Control Module (With Smart Key), Rear Seat, Warmer Relay LH/RH,
E/R Fuse & Relay Box (RLY.2), Diesel Box (Fuel Filter Relay)
MODULE2 7.5A BCM, Panorama Sunroof, Rain Sensor
SPARE 20A -
TRUNK 10A Trunk Lid Relay, Trunk Room Lamp
CLOCK 10A
Driver/Passenger Door Mood Lamp, AMP, BCM, Power Outside Mirror Switch,
A/C Control Module, Crash Pad Mood Lamp, Overhead Console Lamp,
Smart Key Control Module (With Smart Key), Audio, ISG Low DC-DC Converter (Audio)
C/LIGHTER 15A Cigarette Lighter
HTD STRG 15A Steering Wheel Heater
A/CON 7.5A A/C Control Module, E/R Fuse & Relay Box (RLY.14)
WIPER 25A E/R Fuse & Relay Box (RLY.11, RLY.12), Multifunction Switch, Front Wiper Motor
