Hybrid System Overview Charging the plug-in hybrid vehicle
AC Charging Connector Lock
This AC charging connector lock
function prevents an outsider from
removing the charging connector
from the charging inlet.
The driver can select the charge
connector lock mode;
䳜 From the User settings menu
1. Press the MODE button ( )
several times on the steering
wheel until 'User Settings' menu
appears on the LCD.
2. Select 'Convenience → Charging
connector locking mode' with
the MOVE switch ( / ) and
the OK button on the steering
wheel.
䳜 From the infotainment menu (if
equipped)
1. Press SETUP button of the
infotainment system
2. On the infotainment display,
select 'Vehicle → Eco vehicle →
Charging connector locking
mode'.
Connector Lock
Always lock
The connector locks when the
charging connector is plugged into
the charging inlet. The connector is
locked until all doors are unlocked by
the driver. This mode can be used to
prevent charging cable theft.
䳜 If the charging connector is
unlocked when all doors are
unlocked, but the charging cable is
not disconnected within 15 sec
-
onds, the connector will be auto -
matically locked again.
䳜 If the charging connector is
unlocked when all doors are
unlocked, but all doors are locked
again, immediately, the connec
-
tor will be automatically locked
again.
Lock while charging
The connector locks when charging
starts. The connector unlocks when
charging is complete.
Scheduled Charging (if equipped)
䳜 You can set reserved charging
using the Infotainment System.
Refer to the Infotainment System
for detailed information about
setting reserved charging.
䳜 Scheduled charging can only be
done when using a AC charger or
the portable charging cable (ICCB:
In-Cable Control Box).
Always lock Lock while charging
Before
charging
O X
While
charging
O O
After
charging
O X
