Kia XCEED PHEV MY21 - Page 583

85
8
8
Maintenance Light bulbs
Wagon
CUV (16 in tire)
Vehicle condition
Head lamp (LED type)
Ground Height Distance between lamps
Low/High beam Low/High beam
H1' W1'
without driver
[mm (in)]
712 (28) 1,354 (53.3)
with driver
[mm (in)]
706 (27.8) 1,354 (53.3)
Vehicle condition
Front Fog lamp (Bulb type)
Ground Height Distance between lamps
H3 W3
without driver
[mm (in)]
490 (19.3) 1,494 (58.8)
with driver
[mm (in)]
486 (19.1) 1,494 (58.8)
Vehicle condition
Head lamp (LED type) Front Fog lamp (Bulb type)
Ground Height
Distance between
lamps
Ground Height
Distance between
lamps
Low/High beam Low/High beam
H3 W3
H1 W1
without driver
[mm (in)]
743 (29.3) 1,339 (52.7) 423 (16.7) 1,547 (60.9)
with driver
[mm (in)]
737 (29.0) 1,339 (52.7) 429 (16.9) 1,547 (60.9)
CD_PHEV_LHD.book Page 85 Tuesday, November 12, 2019 11:29 PM
