Kicker CX300.1 User Manual

4
GND REM +12V
12V
battery
external fuse
remote turn-on
(see page 5)
bare-metal
chassis ground
bare-metal
chassis ground
d18”
(45cm)
d24”
(60cm)
woofer
MONO OPERATION
minimum impedance of 2 ohms
Model External Fuse
(sold separately)
Power/Ground Wire KICKER Wiring Kit
CX300.1 1 x 40 Ampere 8 Gauge PK8, ZCK84
CX600.1 1 x 80 Ampere 4 Gauge PK4, CK44, ZCK44
CX1200.1 1 x 150 Ampere 4 Gauge PK4, CK44, ZCK44
Install a fuse within 18” (45cm) of the battery and in-line with the power cable connected to your amplifi er. If you
ever need to remove the amplifi er from the vehicle after it has been installed, the ground wire should be the last
wire disconnected from the amplifi er--just the opposite as when you installed it.
