Page #2 background image
2
ZX AMPLIFIERS
ZX.5-SERIES AMPLIFIERS Owner’s Manual
INSTALLATION
Mounting: Choose a structurally sound location to mount your KICKER amplifi er. Make sure there are no items
behind the area where the screws will be driven. Choose a location that allows at least 4” (10cm) of open
ventilation for the amplifi er. If possible, mount the amplifi er in the climate-controlled passenger compartment. Drill
four holes using a 7/64” (3mm) bit and use the supplied #8 screws to mount the amplifi er.
Wiring: Disconnect the vehicle’s battery to avoid an electrical short. Then, connect the ground wire to the
amplifi er. Make the ground wire short, 24” (60cm) or less, and connect it to a paint-and-corrosion-free, solid,
metal area of the vehicle’s chassis. Adding an additional ground wire of this same gauge (or larger) between the
battery’s negative post and the vehicle chassis is recommended.
PERFORMANCE
Authorized KICKER Dealer:
Purchase Date:
Model Number:
Serial Number:
RMS Power:
AMP1 & AMP2 channels driven
@ 14.4V, 4Ω stereo, 1% THD+N
@ 14.4V, 2Ω stereo, 1% THD+N
@ 14.4V, 4Ω mono, 1% THD+N
70W x 4
85W x 4
165W x 2
RMS Power:
SUBWOOFER channel driven
@ 14.4V, 4Ω mono, 1% THD+N
@ 14.4V, 2Ω mono, 1% THD+N
210W x 1
420W x 1
Length 20” (507mm)
Specifi cations:
Height 2-1/8” (54mm)
Width 9-5/8” (244mm)
Frequency Response ± 1dB 25Hz–20kHz
Signal-to-noise Ratio >95dB, A-weighted, re: rated power
Input Sensitivity Low Level: 125mV–5V
High Level: 250mV–10V
Selectable Electronic Crossover Variable HI or OFF (bypass) | 50–200Hz, 12dB/octave
Variable low-pass | 50–200Hz, 24dB/octave (SUB)
Bass Boost Variable 0–18dB @ 40Hz
Subsonic Filter 24dB/octave, fi xed at 25Hz
Pro Tip: To get the best performance from your new KICKER Amplifi er, use genuine KICKER accessories and
wiring.
MODEL: ZX700.5
