Normally, as you release the
STOP
switch
3
, the Tester will become the READY status
(status that the READY message
2
8
appears). In the following cases, however, the Tester will
not become the READY status.
1. The cause of PROTECTION status remaining un-eliminated
(a) The interlock pins of the SIGNAL I/O connector
3
7
on the rear panel are open. (For
details, refer to Section 6.3.3 “Interlock Function.”)
(b) When in DC test (for TOS5101 and TOS5051 only), the high voltage supply section is
overheated.
2. The test voltage remaining undischarged
This is such state that the DANGER lamp
9
remains lighted in spite of that the
TEST message
2
9
has disappeared.
3. A period of approximately 0.5 seconds has elapsed after releasing the
STOP
switch
3
when the DOUBLE ACTION switch of the TEST MODE switch
3
8
is set for ON.
If the DOUBLE ACTION switch of the TEST MODE switch
3
8
is set for ON, the Tester
will become the READY state as you release the
STOP
switch
3
. Then, when a period
of approximately 0.5 seconds has elapsed, the Tester will automatically reset from the
READY status. For details, refer to Section 6.5 “Settings for Special Test Modes.”
4. The
STOP
switch
3
is released while the
START
switch
2
is pressed.
Caution
• If the FAIL MODE switch of the TEST MODE switch
3
8
is set for
ON, resetting from the FAIL status (status that the FAIL message
3
1
appears) or from the PROTECTION status (status that the
PROTECTION message
3
2
appears) can be done with the
STOP
switch
3
only. For details, refer to Section 6.5 “Settings for Special
Test Modes.”
