Chapter 4 DESCRIPTION OF FRONT AND REAR PANEL ITEMS
4-8
4
REMOTE CONTROL Connector
This connector is for remote control of start/stop of test operation from an optional device such
as Remote Control Box (RC01-TOS or RC02-TOS) or H.V Test Probe (HP01A-TOS or
HP02A-TOS).
As you connect the plug of the optional device, the remote control circuit is established and the
REMOTE message
3
4
appears and the local
START
switch
2
is disabled. In this case, the
Tester becomes the PROTECTION status (status that the PROTECTION message
3
2
appears) and the high voltage output is cut off. The STOP operation can be done either locally
from the
STOP
switch
3
on the front panel or remotely from the optional device.
As you disconnect the plug of the optional device, the REMOTE message
3
4
disappears and
the
START
switch
2
is enabled. The Tester becomes the PROTECTION status (status that the
PROTECTION message
3
2
appears) and the high voltage output is cut off.
Caution
For remote-control of the test start/stop operation of the Tester from
other device than one of the optional devices of the Tester, do not use
the
REMOTE CONTROL
connector
4
on the front panel but use
the
SIGNAL I/O
connector
3
7
on the rear panel.
Of the optional H.V Test Probe (HP01A-TOS or HP02A-TOS), the
maximum allowable test voltage is 4 kV when in the AC test mode or
5 kV when in the DC test mode.
Do not remote-control the Tester simultaneously from both
RE-
MOTE CONTROL
connector
4
and
SIGNAL I/O
connector
3
7
. If
you do this, the REMOTE message
3
4
will disappear and the
START
switch
2
will be enabled.
If the Remote Control Box is with its UNCONDITIONAL STOP
function effected, the Tester will not become the PROTECTION
status when the plug of the box is connected to the
REMOTE
CONTROL
connector
4
. When the plug of the HV Test Probe is
connected to the
REMOTE CONTROL
connector
4
. the Tester
will not become the PROTECTION status because the probe is in the
state that its UNCONDITIONAL STOP function is effected.
Be sure to read Section 6.3 “Remote Control” before remote-con-
trolling the Tester.
To reset the Tester from the PROTECTION status, press the
STOP
switch
3
.
