Kikusui TOS5101 - Test Time

Chapter 4 DESCRIPTION OF FRONT AND REAR PANEL ITEMS
4-15
4.1.5 Test Time
14
Keys
The
keys
14
are for increment/decrement of test period of time. The keys are enabled
when the Tester is in the READY status (status that the READY message
2
8
appears) and the
KEYLOCK message
3
3
has disappeared. They are disabled when in the TEST-ON status
(status that the TEST message
2
9
appears) or when the Tester is delivering the result of PASS/
FAIL judgement (when the PASS message
3
0
or the FAIL message
3
1
appears).
If you press the
or
key alone, the rate of increment/decrement is the basic resolution
shown below. If you press it while keeping the
SHIFT
key
16
pressed, the rate of increment/
decrement is ten times of the basic resolution. If you keep them pressed, increment/decrement
repeats automatically.
1.
key
This key increments the test period. The set value is shown on the TIME display
2
6
.
2.
key
This key decrements the test period. The set value is shown on the TIME display
2
6
.
Test period setting range Basic resolution Display format
0.5 to 99.9 s., OFF 0.1 s. □□.□s
100 to 999 s., OFF 1 s. □□□s
For the AC/DC models (TOS5101 and TOS5051), the test period can be set with the
keys
14
for both AC and DC modes of tests. This test condition applies in common to both AC
and DC modes of tests.
