KiloVault HLX+ User Manual

If you are not using the HLX+ Bridge, and the installation location will go below freezing , then the
configuration is limited to 4 HLX+ in parallel or 4 HLX+ in series, but not both, because the HLX+ cannot
coordinate their heaters beyond these configurations.
3.4.2 - With the HLX+ Bridge (coming soon)
The HLX+ Bridge allows the batteries to coordinate their heaters beyond a single string or 4 or 4 single
batteries in parallel. If you are using the HLX+ Bridge with your bank of HLX+ batteries, then you can use
the maximum configuration of 4 parallel strings of 4 batteries in series, even if the installation location
will go below freezing.
4 - Operation
It is very important that your battery chargers (solar charge controller, inverter/charger or AC) can be set
to settings appropriate for the HLX+. If it cannot, please contact KiloVault Technical Support for guidance.
Adjust your settings as necessary until your system performance best fits your power use patterns and
needs.
KiloVault
®
LLC • 330 Codman Hill Road, Boxborough, MA 01719 • +1 (888) 218-5924 • info@kilovault.com • www.kilovault.com
Revision 1.0, 06/2021
Page 10 of 29
