KiloVault HLX+ User Manual

7.1 - Electrical
All Models
Specification
Value
BMS Type
Switching Shunt Resistor
Efficiency
94.50%
Estimated number of cycles at 100% DoD until
80% of rated watt hour capacity remains
2000
Estimated number of cycles at 80% DoD until
80% of rated watt hour capacity remains
5000
High Voltage Shutoff Protection
14.4 ±0.2 V
Low Voltage Shutoff Protection
11.5 V
Maximum Configuration - With Bridge - Any
Temperature Conditions
Up to 4 parallel strings of 4 batteries in series.
Total of 16.
Maximum Configuration - Without Bridge -
Temperature falls below freezing
Up to 4 batteries in series OR 4 batteries in
parallel but not both. Total of 4 batteries.
Maximum Configuration - Without Bridge -
Temperature never falls below freezing
Up to 4 parallel strings of 4 batteries in series.
Total of 16.
Maximum Time Between Charges
6 Months
Minimum Cell Balancing Voltage
3500 mV/Cell
Normal Self-Discharge Current
≤20 mA
Peukert Coefficient
1.05
Rated Voltage
12.8 VDC
Recommended Charge Voltage
14.0 V
Recommended Float Voltage
13.4 V
Self-Discharge Rate
≤2% per month
Standby Mode Activated
Current Draw from Load < 0.25 A (250 mA)
Voltage Configurations
12 V, 24 V, 36 V, 48 V
High Temperature Protection Trigger
≈149° (65°C)
High Temperature Protection Release
≈122°F (50°C)
Low Temperature Protection Trigger
≈32°F (0°C)
Low Temperature Protection Release
≈41°F (5°C)
Heater Behavior
The heater starts at an internal temperature of
≈32°F (0°C) and stops at an internal temperature
of ≈41°F (5°C)
1200 HLX+
Specification
Value
KiloVault
®
LLC • 330 Codman Hill Road, Boxborough, MA 01719 • +1 (888) 218-5924 • info@kilovault.com • www.kilovault.com
Revision 1.0, 06/2021
Page 22 of 29
