Soap Refill Bottle Installation and Removal
Fig. 29
2
1
1
1. Slip the straw into the underside of the
motor module (see gure 26).
2. Push the rell bottle ush to the motor
module until both snaps are secure (see
gure 27).
Note: The red and yellow lights on the
bottom of the soap discharge head
should stop blinking, indicating proper
installation. If the lights continue to flash,
refer to the Troubleshooting Guide.
3. Prime the pump by placing one hand
under the soap discharge head to
activate the motor. Repeat 4 to 5 times
until a consistent shot of foam soap is
discharged (see gure 28).
4. To remove an empty rell bottle, squeeze
the release tabs 1 on the top of the rell
and slide the bottle down 2 and out
(see gure 29).
