5. F 200: Configuration of the channels and
measurement units
This folder allows to activate the channels and to set measurement unit for each channel.
5.1. Activate a channel
The transmitter is powered on.
➢ Press OK.
➢ Enter the activation code (see page 9).
➢ Press OK.
➢ Press Up key to go to F 200 folder.
➢ Press twice OK.
“SDE” is displayed below “F 200”.
➢ Press OK.
“SDE” for probe or “OFF” for deactivated channel or “PRES” for pressure blinks.
➢ Press Up and Down key to select:
• “SDE”: channel is activated with a measurement probe
• “PRES”: channel is activated with a pressure board
• “OFF”: channel is deactivated
➢ Press OK.
The last zero of F200 blinks.
“F200” folder allows to activate the channel 1 of the transmitter.
To activate channels 2 and 3 go to the following folders:
• F210 for channel 2
• F220 for channel 3
➢ Perform the same procedure as for the channel 1.
5.2. Assign a measurement unit to a channel
The transmitter is powered on and a channel is activated.
“F 200” folder is displayed.
➢ Press Up key.
“F 201” sub-folder is displayed with the unit corresponding to the channel 1 below.
➢ Press OK.
The unit blinks.
➢ Press Up and Down keys to select the required unit.
➢ Press OK.
“---” sign means that the channel is deactivated.
“F201” sub-folder allows to select the unit for the channel 1.
To select the unit for channels 2 and 3, go to the following folders:
• F211 for channel 2
• F221 for channel 3
➢ Perform the same procedure as for the unit selection for the channel 1.
F 200: Configuration of the channels and measurement units 13
