6. F 300: Manage the analogue outputs
6.1. Set the analogue outputs
The transmitter is powered on.
➢ Press OK.
➢ Enter the activation code (see page 9).
➢ Press OK.
➢ Press Up key to go to F 300 folder corresponding to the analogue output of the channel 1 then press twice OK.
“F 300” is displayed with the analogue output below.
➢ Press OK.
The analogue output blinks.
➢ Press Up or Down key to select the required output signal:
• 4-20 mA
• 0-20 mA
• 0-10 V
• 0-5 V
➢ Press OK.
“F300” folder is for the analogue output of the channel 1.
For the channels 2 and 3, go to the following folders:
• F310 for the channel 2
• F320 for the channel 3
➢ Perform the same procedure as for the channel 1.
6.2. Set the ranges of the analogue outputs
This function allows to modify the ranges of the analogue outputs.
Values to enter depend on the unit of measurement and not on the measurement range of the transmitter.
Ex: on a CPE 310-S pressure transmitter (0 to ±100 Pa) with a reading in mmH
2
O, the minimum and maximum ranges
must be configured on a measuring range from 0 to ±10 mmH
2
O. See conversion chart page 16.
The transmitter is powered on.
➢ Press OK.
➢ Enter the activation code (see page 9).
➢ Press OK.
➢ Press Up key to go to F 301 folder corresponding to the minimum range of the channel 1.
➢ Press OK.
The 1
st
digit of the minimum range blinks.
➢ Enter with Up and Down keys the figure value or the negative sign of the value then press OK.
The 2
nd
digit blinks.
➢ Enter with Up and Down keys its value then press OK.
➢ Perform the same procedure for the following figures.
➢ Press OK when the last figure is configured.
F 301 blinks, the minimum range is configured.
➢ Press Up key then press OK to enter in the folder F 302 corresponding to the high range of the channel 1.
The 1
st
digit of the high range blinks.
➢ Enter with Up and Down keys the figure value or the negative sign of the value then press OK.
The 2
nd
digit blinks.
➢ Enter with Up and Down keys its value then press OK.
14 F 300: Manage the analogue outputs
