9. Functions recap and Modbus connections
9.1. F 100: configure the transmitter
Code Register type Modbus Description Possibilities
F 100 Real 1000 Serial number of the
transmitter
F 101 - 1010 Firmware version
- U32 1020 Transmitter ID
- U32 1030 Probe ID
F 135 Boolean 1350 Sound
F 140 Boolean 1400 Keypad locking 0: deactivated
1: activated
F 141 U16 1410 Safety code
F 150 U8 1500 Modbus slave number From 1 to 255
F 151 Enumeration 1510 Modbus communication
speed
2400 / 4800 / 9600/ 19200 /
38400 / 115200 bds
F 170 U32 1700 Activation of the high
resolution in pressure option
0: deactivated
1: activated
F 171 U32 1710 Activation of the Modbus
option
0: deactivated
1: activated
F 190 Boolean 1900 Back to factory configuration
9.2. F 200: configure the channels and the measurement units
Code Register type Modbus Description Possibilities
F 200 Enumeration 2010 Selection of probe or board Probe / board / deactivated
F 201 Enumeration 2000 Unit selection of the channel 1 According to probe and board
F 210 Enumeration 2110 Selection of probe or board Probe / board / deactivated
F 211 Enumeration 2100 Unit selection of the channel 2 According to probe and board
F 220 Enumeration 2210 Selection of probe or board Probe / board / deactivated
F 221 Enumeration 2200 Unit selection of the channel 3 According to probe and board
9.3. F 300: manage the analogue outputs
Code Register type Modbus Description Possibilities
F 300 Enumeration 3000 Analogue output of the channel 1 4-20 mA / 0-20 mA / 0-10 V / 0-5 V
F 310 Enumeration 3100 Analogue output of the channel 2 4-20 mA / 0-20 mA / 0-10 V / 0-5 V
F 320 Enumeration 3200 Analogue output of the channel 3 4-20 mA / 0-20 mA / 0-10 V / 0-5 V
F 301 Real 3010 Low range of the channel 1 From -1999 to 9999
F 302 Real 3020 High range of the channel 1 From -1999 to 9999
F 311 Real 3110 Low range of the channel 2 From -1999 to 9999
F 312 Real 3120 High range of the channel 2 From -1999 to 9999
22 Functions recap and Modbus connections
