Kimo CPE 311-S User Manual

Code Register type Modbus Description Possibilities
F 321 Real 3210 Low range of the channel 3 From -1999 to 9999
F 322 Real 3220 High range of the channel 3 From -1999 to 9999
F 303 Enumeration 3010 Channel 1 diagnostic: generation of a
voltage or a current
Generation according to the output
signal
0-10 V 0-5 V 0-20 mA 4-20 mA
0 V 0 V 0 mA 4 mA
5 V 2.5 V 10 mA 12 mA
10 V 5 V 20 mA 20 mA
F 313 Enumeration 3110 Channel 2 diagnostic: generation of a
voltage or a current
Generation according to the output
signal
0-10 V 0-5 V 0-20 mA 4-20 mA
0 V 0 V 0 mA 4 mA
5 V 2.5 V 10 mA 12 mA
10 V 5 V 20 mA 20 mA
F 323 Enumeration 3210 Channel 3 diagnostic: generation of a
voltage or a current
Generation according to the output
signal
0-10 V 0-5 V 0-20 mA 4-20 mA
0 V 0 V 0 mA 4 mA
5 V 2.5 V 10 mA 12 mA
10 V 5 V 20 mA 20 mA
9.4. F 400: manage the alarms
Code Register type Modbus Description Possibilities
F 400 Enumeration 4000 Alarm mode of the alarm 1 1: None
2: Rising edge
3: Falling edge
4: Monitoring
F 401 U8 4010 Channel selection alarm 1 Channel 1
Channel 2
Channel 3
F 402 Real 4020 Threshold 1 setting of the
alarm 1
According to the connected probe
F 403 Real 4030 Threshold 2 setting or
hysteresis of the alarm 1
According to the connected probe
F 404 U16 4040 Delay-time 1 setting of the
alarm 1
From 0 to 600 s
F 405 U16 4050 Delay-time 2 setting of the
alarm 1
From 0 to 600 s
F 406 Boolean 4080 Audible alarm 1 1: activated / 0: deactivated
F 407 U8 4070 Alarm 1 acknowledgement
duration
From 0 to 60 minutes
Functions recap and Modbus connections 23
