14
interface (-)
X2
24VS/GNDS
Logic power supply:‖18VDC～30VDC 1A‖
24VB/GNDB
Power supply for brake ―18VDC～30VDC 0.5A‖ (CD622S 2A)
BR+/BR-
Brake interface
X3
CD412S
CD422S
U/V/W/PE
Motor cable interface
L/N
Main power supply（Single-phase AC220V）
RB+/RB-
Braking resistor interface
X5
CD412S
CD422S
CD432S
CD622S
RS232
RS232 interface
X6
ENCODER
IN
Encoder cable interface
X7
CD432S
CD622S
R/S/T
Main power supply（ CD432S： Single phase or 3-phase
AC220V，CD622S：3-phase AC380V）
RB+/RB-
Braking resistor interface
DC+/DC-
DC bus power supply(Cannot use together with R/S/T)
