Chapter 4 Wiring Guide of VFD
50
Category
Terminals
Name
Function description
Specification
Relay output
terminal 1
R1a
Relay output
Can be defined as multi-function relay
output terminal(Refer to the A6.16 for detail)
R1a-R1b.Normally closed，
R1a-R1c.normally open
Contact capacity .
AC250V/2A(COSΦ＝1)
AC250V/1A(COSΦ＝0.4)
DC30V/1A
Input voltage for
overvoltage class of relay
output terminal
is overvoltage class II
R1b
R1c
