Kinco FV20-4T-0037G/0055L User Manual

6
6
Item
Description
Operation panel
LED Display
Display frequency setting, frequency output, voltage output, current output
and so on, about 20 parameters.
Parameters
copy
Copy parameters by operation panel.
Keys lock and
function
selection
Lock part of keys or all the keys.
Define the function of part of keys, in case of misoperation.
Protection function
Open phase protection (optional), over current protection, overvoltage
protection, undervoltage protection, overheat protection, and overload
protection and so on.
Environment
Operating site
Indoor, installed in the environment free from direct sunlight, dust, corrosive
gas, combustible gas, oil mist, steam and drip.
Altitude
Derated above 1000m, the rated output shall be decreased by 10% for every
rise of 1000m
Ambient
temperature
-10℃~40℃, derated at 40℃~ 50℃
Humidity
5%~95%RH, non-condensing
Vibration
Less than 5.9m/s² (0.6g)
Storage
temperature
－40℃～＋70℃
Structure
Protection
class
IP20
Cooling
method
Air cooling, with fan control.
Installation method
Wall-mounted
Efficiency
Power under 45kW≥93%；Power above 55kW≥95%
2.4 Introduction of product series
Table 2-1 Series of Kinco VFD
Model of VFD
Rated capacity
（kVA）
Rated input current
（A）
Rated output current
（A）
Motor power
（kW）
FV20-2S-0004G
1.0
5.3
2.5
0.4
FV20-2S-0007G
1.5
8.2
4.0
0.75
FV20-2S-0015G
3.0
14.0
7.5
1.5
FV20-2S-0022G
4.0
23.0
10.0
2.2
FV20-4T-0007G/0015L
1.5
3.4
2.3
0.75
FV20-4T-0015G/0022L
3.0
5.0
3.7
1.5
FV20-4T-0022G/0037L
4.0
5.8
5.5
2.2
FV20-4T-0037G/0055L
5.9
10.5
8.8
3.7
FV20-4T-0055G/0075L
8.5
14.5
13.0
5.5
