2.7 Braking Resistor Selection
VFD Model
Braking
Unit
Braking resistor
Standard
resistance
Qty.
Min. resistance
Standard power
FV20-2S/2T-0004G
Built-in
200Ω
1
100Ω
100W
FV20-2S/2T -0007G
150Ω
1
100Ω
150W
FV20-2S/2T -0015G
150Ω
1
100Ω
150W
FV20-2S/2T -0022G
50Ω
1
35Ω
400W
FV20-2S/2T -0037G
45Ω
1
35Ω
450W
FV20-2S/2T-0055G
50Ω
1
25Ω
1600W
FV20-2S/2T-0075G
40Ω
1
25Ω
2000W
FV20-2S/2T-0110G
27.2Ω
1
20Ω
2000W
FV20-4T-0007G/0015L
750Ω
1
125Ω
110W
FV20-4T-0015G/0022L
400Ω
1
100Ω
260W
FV20-4T-0022G/0037L
250Ω
1
100Ω
320W
FV20-4T-0037G/0055L
150Ω
1
66.7Ω
550W
FV20-4T-0055G/0075L
100Ω
1
66.7Ω
800W
FV20-4T-0075G/0110L
75Ω
1
66.7Ω
1070W
FV20-4T-0110G/0150L
50Ω
1
25Ω
1600W
FV20-4T-0150G/0185L
40Ω
1
25Ω
2000W
FV20-4T-0185G/0220L
32Ω
1
20Ω
4800W
FV20-2S/2T-0150G
20Ω
1
14Ω
2000W
FV20-2S/2T-0185G
16Ω
1
14Ω
4800W
FV20-2S/2T-0220G
13.6Ω
1
10Ω
4800W
FV20-4T-0220G/0300L
27.2Ω
1
20Ω
4800W
FV20-4T-0300G/0370L
20Ω
1
14Ω
6000W
FV20-4T-0370G/0450L
16Ω
1
14Ω
9600W
FV20-4T-0450G/0550L
15Ω
1
13.6Ω
9600W
FV20-4T-0550G/0750L
External
20Ω
2
13.6Ω
6000W*2
FV20-4T-0750G/0900L
20Ω
2
13.6Ω
9600W*2
FV20-4T-0900G/1100L
18Ω
3
13.6Ω
9600W*3
FV20-4T-1100G/1320L
18Ω
3
13.6Ω
6000 W*3
FV20-4T-1320G/1600L
10Ω
1
4Ω
30KW
FV20-4T-1600G/1850L
8Ω
1
4Ω
30KW
FV20-4T-1850G/2000L
6Ω
1
4Ω
30KW
FV20-4T-2000G/2200L
5Ω
1
4Ω
30KW
