Kinco FV20-4T-0037G/0055L User Manual

Quick start guide
Wiring
Terminal
Description
Connect
R/S/T
VFD Power input
Connect to Power supply
+/-
Bus DC +/-
Connect to Brake Unit
+/PB
Brake Resistor
Connect to Brake Resistor
U/V/W
VFD Output
Connect to Motor
PE
VFD Ground
Connect to Ground
X1/X2
Digital Input
Connect to a Switch
AI1
Analog Input
Connect to a Sliding rheostat
Y1
Digital Output
Connect to PLC
AO1
Analog Output
Connect to Ampere meter
Ra/Rc
Relay Output
Connect to Relay
Common Setting Parameters
Code
Description
Code
Description
A0.01
Control mode
A6.30
AO1 Function
A0.02
Frequency source
A7.00
PG card Type
A0.03
Giving Frequency
A7.01
PG card Pulses / revolution
A0.04
Command selection
A8.01
Fault mask selection 1
A0.06
Acc. time
b0.00
Asynchronous motor 1 power
A0.07
Dec. time
b0.04
Asynchronous motor 1 pole logarithm
A6.00
X1 Function
b0.15
Synchronous motor 1 power
A6.01
X2 Function
b0.19
Asynchronous motor 1 pole logarithm
A6.09
Terminal control mode
b3.00
Communication configuration
A6.14
Y1 Function
b3.01
Address
A6.16
Relay Function
b4.03
Parameter initialization
A6.27
Y1 High Speed Pulse Output
Common Display Parameters
Code
Description
Code
Description
d0.04
Output Frequency
d0.16
AI1 input voltage
d0.05
Output Voltage
d0.28
Radiator temperature
d0.06
Output Current
d1.00
Fault record 1
d0.09
Motor Power
d1.01
Fault Bus Voltage
d0.11
Motor Frequency
d1.02
Fault current
d0.13
Inverter running status
d1.03
Fault frequency
d0.14
Switch input status
d2.02
Software version
d0.15
Switch output status
d2.07
Software date

Kinco FV20-4T-0037G/0055L Specifications

General

Brand	Kinco
Model	FV20-4T-0037G/0055L
Category	DC Drives
Language	English
