2.1.3 Serial Communication Port
HMI-PLC HP043-20DT provides 1 communication ports,PORT1 .It supports baudrate up to
115.2kbps.PORT1 can be used as programming port and also support Modbus RTU slave
protocol and free protocol.
HP043-20DTC、HP070 Providing 2*RS485 COM,which is Port1 and Port2,the Baudrated up
to 115.2Kbps. Port 1 could use as programming port,as well as Modbus RTU Master/Slave
protocol,and free communication. Port 2 could use as Modbus RTU Master/Slave
protocol,free communication.
And please refers to 2.2 Wiring diagram to know about their pin assignment.
2.1.4 High Speed Counter and High Speed Pulse Output
HP043 provides 4 high speed counters (HSC0~HSC3).（Note：HSC2 of HP043-20DTC could
only support mode0 when input are I0.4). HP070 provides 2 high-speed counters, which are
HSC0, HSC1,High speed counter supports multiple modes: single phase,
CW/CCW(Up/Down),AB phase (1 multiplication and 4 multiplication).HSC0 and HSC1 can
support up to 50KHz(Include single phase and AB phase).HSC2 and HSC3 can support up to
20KHz for single phase and 10 KHz for AB phase.
CPU
Single phase
AB phase
HSC0 and HSC1
HSC2 and HSC3
HSC0 and HSC1
HSC2 and HSC3
HP043
50K
20K
50K
10K
HP070
50K
/
20K
/
HMI-PLC HP043 provides 3 high speed pulse outputs(Q0.0,Q0.1 and Q0.4).HP070 provides
2 high-speed outputs, the channels are Q0.0, Q0.1, All support PTO and PWM.Q0.0 and Q0.1
support up to 50KHz (The resistor of load should be less than 3KΩ).
