3.2.3 High speed counter
HP043 provides 4 high speed counters HSC0-HSC3.while HP070 provides 2 high-speed
counters, are HSC0, HSC1.High speed counter supports multiple modes: single phase,
CW/CCW,AB phase (1 multiplication and 4 multiplication).Note: HP043-20DTC's HSC2
only supports mode 0, and the input is I0.4.
All high speed counter can support maximum 32 PV and support 32 “CV=PV” interrupts. PV
can be set as relative value or absolute value. If it is relative value,
CPU
Single phase
ABphase
HSC0 and HSC1
HSC2 and HSC3
HSC0 and HSC1
HSC0 and HSC3
HP043
50K
20K
50K
10K
HP070
50K
/
20K
/
3.2.3.1 Operation Modes and Inputs of the High-speed Counters
Input signals of high-speed counter include: clock (input impulse), direction, start and reset.
In different operation modes input signals is different. Please see below:
HSC 0
Mod
e
Description
I0.1
I0.0
I0.5
0
Single-phase up/down counter
with internal direction control:
SM37.3
Clock
1
Reset
2
Reset
Start
3
Single-phase up/down counter
with external direction control
Clock
Direction
4
Reset
Direction
6
Two-phase counter with up/down
clock inputs
Clock
Down
Clock Up
9
A/B phase quadrature counter
Clock A
Clock B
HSC1
Mode
Description
I0.4
I0.6
I0.3
I0.2
0
Single-phase up/down counter
with internal direction control:
SM47.3
Clock
1
Reset
2
Reset
Start
