Kinco HP043 User Manual

Kinco-HP
User Manual
44
97
“CV=PV”interrupt of 2nd PV
…
…（Plus 1）
127
“CV=PV”interrupt of 32nd PV
HSC2
128
“CV=PV”interrupt of 1st PV
129
“CV=PV”interrupt of 2nd PV
…
…（Plus 1）
159
“CV=PV”interrupt of 32nd PV
HSC3
160
“CV=PV”interrupt of 1st PV
161
“CV=PV”interrupt of 2nd PV
…
…（Plus 1）
191
“CV=PV”interrupt of 32nd PV
3.2.3.5 How to use high speed counter
 Method 1:Use instructions for programming
1)Configure the control byte of HSC and define the current value (i.e. starting value) and the
preset value.
2)Use HDEF instruction to define the counter and its operation mode.
3)(Optional) Use ATCH instruction to define the interrupt routines.
4)Use HSC instruction to start the high-speed counter.
 Method 2:Use wizard of HSC
In HMI- PLC, it provides configuration wizard for high speed counter. Users can use the
wizard to configure all high speed counters and don’t need to program. The wizard is as
following figure:
After using wizard to configure HSC, user also can use “Method 1” to modify the parameters
of HSC.
