2.4 Technical Specification
 DI Specifications
Input type
Source/Sink
Rated input voltage
DC 24V (Max. 30V)
Rated input current
3.5mA@24VDC
Max input voltage of logic 0
5V@0.7mA
Minimum input voltage of logic 1
Common channel:11V@2.0mA
Input filter time delay
· off-to-on
· on-to-off
Common channel: 15μs; HSC channel:
10μs(50k)
Common channel: 60μs; HSC channel: 6μs
(50k)
Isolation between input and internal
circuit
· Mode
· Voltage
Opt-electrical isolation
500VAC/1 min

DO Specifications(Transistor type)
Output type
Source
Rated power supply voltage
DC24V, allowance range:
DC20.4V—DC28.8V.(Same as power supply)
Output current per channel
Rated current:200mA @24VDC
Instant impulse current per channel
1A,less than 1s
Output leakage current
Max.0.5цA
Output impedance
Max. 0.2Ω
Output delay
· off-to-on
· on-to-off
Common channel: 15μs; HSC channel:
10μs(50k)
Common channel: 35μs; HSC channel: 6μs(50k)
Protection：
·Reverse polarity protection of power
supply
·Inductive load protection
·Short-circuit protection
·Reverse polarity protection of output
No
Yes
Yes
Yes, less than 10s.
Isolation between output and internal
circuit
Opto-electrical isolation

Kinco HP043 Specifications

General

Brand	Kinco
Model	HP043
Category	Control Unit
Language	English
