Kinco HP043 User Manual

Kinco-HP
User Manual
22
Chapter 3 Software Introduction
3.1 HMI programming
HMI programming software: Kinco HPBuilder. Download link for HMI software
http://en.kinco.cn
3.1.1 Create project
Process to create project based on Kinco HPBuilder.
1, create project
Open Kinco HPBuilder
1.1 create new project
（1） click menu【File】--【new】 to create project；
（2） input project name；
（3） Select path for saving project；
（4） Click【OK】
1.2 choose device, connect and setup parameters
① choose device-choose communication
Drag “Serial port”in 【Graph element window】--【Connector】 to construct window.
②Choose device—choose HMI type
Drag “HP043”in 【Graph element window】--【HMI】to construct window.
