User Manual
40
SM37.6
SM47.6
SM57.6
SM127.6
Write new current value in HSC? 0= NO; 1= Yes
SM37.7
SM47.7
SM57.7
SM127.7
Allow this high-speed counter? 0=NO; 1= YES
HSC0
HSC1
HSC2
HSC3
Description
SMD38
SMD48
SMD58
SMD128
Current value
SMD42
SMD52
SMD62
SMD132
Pre-set value
HSC0
HSC1
HSC2
HSC3
Description
SM141.0
SM151.0
SM161.0
SM171.0
Use multiple preset value:0=No. 1=Yes.
SM141.1
SM151.1
SM161.1
SM171.1
Preset value type:0=Absolute value.
1=Relative value.
SM141.2
SM151.2
SM161.2
SM171.2
Preset value comparison interrupt
(“CV=PV”) cyclic execution.
0=No. 1=Yes.
Note:Only valid when preset value is relative
value.
SM141.3
SM151.3
SM161.3
SM171.3
Reserved
SM141.4
SM151.4
SM161.4
SM171.4
Update multiple PV segment and preset
value:0=No. 1=Yes
SM141.5
SM151.5
SM161.5
SM171.5
Reset interrupt variable:0=Yes. 1=No.
SM141.6
SM151.6
SM161.6
SM171.6
Reserved
SM141.7
SM151.7
SM161.7
SM171.7
Reserved
HSC0
HSC1
HSC2
HSC2
Description
SMW142
SMW152
SMW162
SMW172
Starting value of preset value table （ It is
offset corresponding to VB0),it must be odd
value.
It needs to pay attention that not all the control bits of the control byte is suitable for all
operation mode. For example, “Counting direction” and “Write counting direction in HSC” can
be only used in mode 0,1 and 2 (Single-phase up/down counter
with internal direction control),if the operation mode is with external direction control, then
these two bits will be ignored.
The control byte, current value and preset value are 0 by default after power on
 Status Byte
In SM area, each high-speed counter has a status byte, which indicates the current status
of high speed counter.
