Kinco HP043 User Manual

Kinco-HP
User Manual
6
Type J, Type K, Type E, Type S
optional,Internal/external
compensation
Accuracy ： 24 bits ADC ,0.1%
F.S.
Expansion
No
Programming port
USB2.0
Serial port
1*RS485，max. 115.2kbps.
Programming port 、 Modbus
RTU master and slave 、 free
protocol
2*RS485，max. 115.2kbps.
PORT1 support Programming
port、 Modbus RTU master and
slave、free protocol.
PORT2 support Modbus RTU
master and slave、free protocol
High speed counter
Single
Double
4
4, HSC0、HSC1 max.50KHz，HSC2、HSC3 max.20KHz
4, HSC0、HSC1 max.50KHz，HSC2、HSC3 max.10KHz
High speed output
3
0 and 1 max.50KHz（The load resistor is less than 3KΩ if maximum
frequency）.
2 max. 10KHz.
Interrupt
4 ，I0.0-I0.3 can be on/off interrupt.
Memory area
Programming
Max. 4K instruction
Users data
M area 1K bytes；V area 4K bytes
DI
2 bytes
DO
2 bytes
AI
2 bytes
