2M1180N/2M2280N Stepper Motor Driver
3
Chapter 2 Product Overview
2.1 Product Acceptance
Upon receiving the product, please check the following items:
Make sure the driver model is consistent with that ordered.
Unpack the product and make sure it is free from damage and no part is missing.
Make sure all set screws in the driver are securely tightened.
Check the received product against the packing list and contact our customer service
center in time if any part is missing.
2M2280N driver or 2M1180N driver
Product Services Directory
Certificate of Conformity
2kΩ metal film DIP resistor
Length 10mm diameter φ10 insulated terminals
Length 15mm diameter φ12 insulated terminals
2.2 Product Model Description
2.3 Product Overview
N series drivers are the latest high-subdivision stepper motor drivers launched by Kinco
Electric (Shenzhen) Ltd. With the DSP single-chip microcomputer as the control core,
these products adopt vector current control algorithm and are suitable for driving
2-phase hybrid stepper motors under various brand names. The application of
advanced vector control algorithm reduces remarkably the noise and vibration of the
motors during operation, and enables the stepper motors to deliver a noise and stability
level comparable to that of servo motors. The brand-new radiator design enables the
drivers to meet the strict safety requirements while keeping a compact structure.
