User Manual
6
Chapter 3 Product Parameters and Installation
3.1 Product Parameters
Please learn carefully the driver parameters before use. Make sure the power supply and
operating environment conform to relevant requirements.
Table 1 Electrical Specifications
Parameter
Description
Input voltage
2M2280N: Single-phase 220V AC +/-15% (50Hz)(187VAC~253VAC)
2M1180N: Single-phase 77V AC~123VAC, (50Hz)
Phase
current(peak)
4.5A,5A,5.5A,6A,6.5A,7A,7.5A,8A
Micro step
2/4/5/8/10/16/20/32/50/64/100/128
Input signal
Three control signal ports: PLS(CW)/DIR(CCW)/FRE; current range:
6~16 mA
Signal input
method
PLS+DIR; CW/CCW
Output signal
ERR, open collector output
Automatic half
current
Waiting time for automatic half current: 1.5s; phase current decreased
by 50%
Protection
Over-voltage, under-voltage, over-current, and overheat protection
Absorbing circuit*
Need customize, used to absorb the energy feed back by the motor
Table 2 Operating Environment
Cooling method
Forced air cooling
Environment
Operation environment
Avoid the environment with great amount of
metallic powder, oil mist, or erosive gases.
Operation humidity
<85%, RH (non-condensing or water drops)
Operation temperature
0~ +40
Storage temperature
-20 ~ +70
Weight (net)
1.5Kg
Dimensions
201mm× 147mm× 66mm
Ingress protection
IP20
3.2 Description of WiringTerminal
Wiring terminals of the driver are divided into three types: control signal port, motor power
cable port, and power input port. Control signal port can receive differential signal,
single-ended common-cathode and common-anode signals, and can prevent the interference
of ambient environment on the driver with the built-in high-speed optocoupler. The twisted
pairs are recommended as signal lines for enhanced interference immunity in environments
with strong electromagnetic interference. The definitions of the driver ports are detailed
below.
